dbmlgraph

DBML → LLM-ready markdown knowledge graph. Reads a .dbml schema, merges an optional business-context overlay, and writes a set of plain markdown files (plus a JSONL export) sized for AI coding agents to consume without any special tooling.

_{Recorded with vhs from demo/demo.tape against the sample schema in demo/. Regenerate with npm run build && cd demo && vhs demo.tape.}

What / Why

AI agents working against a database don't need raw DDL — they need schema semantics: what a table is for, what a column means, how a derived value is computed, what each enum value represents, and how tables relate to each other. Column types and foreign keys answer "what", not "why", and "why" is what an agent needs to write a correct query or avoid a subtle business-rule violation.

Existing schema-doc generators (tbls, LLMSchema, and similar tools) connect to a live database and reflect its structure, but structure is all a live connection can offer — there is no live column that holds "this formula sums order_items, not orders" or "status ACTIVE means the branch is currently reporting actuals." dbmlgraph takes a different input: DBML, the format schema authors already hand-write and annotate, often before the database even exists. On top of the parsed DBML it merges a separate overlay layer — small YAML files, one per table, that carry the business context DBML's own note fields don't have room for (structured meanings, generated-value provenance, formulas, enum semantics). The overlay never invents or overrides structure; it only annotates what the DBML already declares, and lint catches drift the moment an overlay refers to a table or column that no longer exists. Output is plain markdown any agent can cat, split into three grains — a schema-wide index, one file per domain, one file per table — so a small-context agent loads only the slice it needs, plus a JSONL export for RAG pipelines that want one chunk per table.

How it compares

The closest tools solve a different problem: they document a database that already exists, by connecting to it. dbmlgraph works from DBML you write, and its whole point is the business-context layer a live connection can't provide.

	dbmlgraph	tbls	@dbml/cli
Input	DBML file	Live database (DSN)	DBML file
Needs a DB connection	No	Yes	No
Business-context layer (meaning, formulas, enum semantics)	Yes, via overlays	Column comments only	No
Built for LLM / agent consumption	Yes	No (human docs)	No
RAG export (JSONL, one chunk per table)	Yes	No	No
Output split by grain (index / domain / table)	Yes	Per-table pages	No
Lint for documentation gaps	Yes (`W001`–`W003`)	Yes (column comments)	No
ER diagrams	Per-domain (Mermaid)	Yes (many formats)	No
Identifier search across the whole schema	Yes (`find`)	No	No
One-command agent wiring (Claude Code, AGENTS.md)	Yes (`install`)	No	No
Primary job	Feed schema meaning to AI agents	Document a live DB in CI	Convert DBML ↔ SQL

Use tbls when you have a running database and want rich human documentation in CI. Use @dbml/cli when you want to turn DBML into SQL or vice versa. Use dbmlgraph when an AI agent needs to understand what your schema means, not just its shape.

Requirements

Node.js 20 or newer. Check with node --version. npm ships with Node, so you need nothing else.
A DBML file. Hand-written or exported from dbdiagram.io. dbmlgraph reads this file; it never connects to a database, so no driver, credentials, or running server are involved.
Overlay YAML files (optional). Add these when you want business context on top of the schema. Skip them and the tool still runs on DBML alone.

No global config, no database connection, no network access at runtime.

Install

npm i -g dbmlgraph
# or, without installing:
npx dbmlgraph --help

New to the tool? The step-by-step guide walks from an empty folder to a full knowledge graph, covers every flag, and lists the behaviors that surprise people. The rest of this README is the reference.

Quick start

dbmlgraph init -i schema.dbml -o overlays/                 # scaffold blank overlay stubs (once, per new schema)
dbmlgraph generate -i schema.dbml --overlays overlays/ -o out/ --link-style md
dbmlgraph lint -i schema.dbml --overlays overlays/
dbmlgraph export -i schema.dbml --overlays overlays/ -o out/export.jsonl

init reads the DBML and emits one blank, correctly-keyed overlay stub per table (every column and enum value pre-listed, meanings blank) into the overlays directory — so you only fill in meaning, never the mechanical scaffold. It never overwrites an existing overlay file; already-authored tables are skipped and reported. id, created_at, updated_at are omitted by default (override with --exclude-columns).

Config file

Drop a .dbmlgraph.yml in your project root and run the commands with no flags:

# .dbmlgraph.yml
input: schema.dbml
overlays: overlays/
out: graph/
linkStyle: obsidian        # obsidian | md
# excludeColumns: [id, created_at, updated_at]

dbmlgraph generate     # reads .dbmlgraph.yml — no repeated flags
dbmlgraph lint
dbmlgraph export       # writes JSONL to `out`
dbmlgraph init         # writes stubs to `overlays`

Every key is optional. An explicit flag always overrides the config (generate --link-style md beats linkStyle: obsidian). Point at a different file with -c/--config <path>; a missing default file is fine (config is optional), but a missing explicit --config path is an error. For init, the config's overlays is the stub destination (out is only used by generate/export).

generate writes:

out/
├── AGENTS.md               # navigation instructions for AI agents landing in this dir
├── _index.md              # schema-wide index, one line per table, grouped by domain
├── domains/
│   ├── commerce.md         # tables in this domain + local ER diagram + cross-domain refs
│   ├── identity.md
│   └── ungrouped.md        # tables outside any TableGroup land here
└── tables/
    ├── orders.md            # full detail: columns, enums, relationships, indexes, rules
    ├── users.md
    ├── settings.md
    └── audit_log.md

generate always writes AGENTS.md at the output root — a landing doc that tells an AI agent dropped into this directory how to navigate it (start at _index.md, drill into domains/ then tables/, prefer dbmlgraph query over opening files by hand). It's regenerated on every run, so don't hand-edit it; edits are overwritten on the next generate.

Overlay format

One YAML file per table, filename (minus extension) = table name. Every field is optional — write only what adds context beyond the DBML itself.

# overlays/branch.yml — file name = table name
purpose: >
  One-paragraph table purpose.
rules:
  - Business rule one
columns:
  some_column:
    meaning: What this column means
    generated: How the value is produced
    formula: "SUM(x * y)"
  status_column:
    enum:
      ACTIVE: what this value means
      CLOSED: what this one means
  channel:                          # varchar column whose values live in a note string
    values:
      WEB: Online storefront
      POS: In-store point of sale
  data_type:
    open: true                      # values are illustrative, not exhaustive
    values:
      ACTUAL_PRODUCTION_MO: MO-level production actuals

purpose — one-paragraph description of what the table represents, shown under the table's # name heading and inlined next to its entry in _index.md and its domain page.
rules — plain-language business rules, rendered as a ## Rules list at the bottom of the table page.
columns.<name>.meaning / .generated / .formula — free-form notes on a specific column, rendered in the column's meaning cell. When meaning is set it replaces the DBML note for that column (the note is not appended); leave it blank to fall back to the note.
columns.<name>.enum — maps enum value names to their business meaning. Only valid on a column whose DBML type is an enum; dbmlgraph resolves the enum by the column's declared type and applies the meanings to that enum's values.
columns.<name>.values — maps allowed values to their meaning for a varchar column whose value set lives in a note: 'A | B | C' string rather than a DBML enum. Rendered as a structured entry under ## Enums. Set columns.<name>.open: true when the values are illustrative (e.g. ...) rather than an exhaustive closed set.

Output format

Sample table node (tables/orders.md), generated from the bundled test fixture:

---
table: orders
domain: commerce
refs_out: [users]
refs_in: []
---
# orders
> Order header. One row per checkout.

## Columns
| column | type | constraints | meaning |
|---|---|---|---|
| id | bigint | PK, null |  |
| user_id | bigint | not null |  |
| status | order_status | null, default pending |  |
| total | numeric | not null | Formula: `SUM(order_items.qty * order_items.price)` |

## Enums
`order_status`: pending = awaiting payment confirmation · shipped = handed to courier · cancelled = user or system cancelled

## Relationships
- → [users](users.md) via user_id (many-to-one)

## Indexes
- idx_user_status on (user_id, status)

## Rules
- Never delete; cancel via status

Lint rules

dbmlgraph lint exits 1 when any error is present, so it can gate CI. Warnings never fail the build — they flag missing context, not broken overlays.

Code	Severity	Meaning
E001	error	Overlay file refers to a table that doesn't exist in the DBML
E002	error	Overlay refers to a column that doesn't exist on that table
E003	error	Overlay's `enum` block is on a non-enum column, or names a value the enum doesn't have
W001	warning	Table has no overlay `purpose`
W002	warning	Column has neither a DBML `note` nor an overlay `meaning`
W003	warning	Enum value has neither a DBML `note` nor an overlay meaning

--exclude-columns exempts a comma-separated column list (e.g. id,created_at,updated_at, the built-in default) from W002 — housekeeping columns that rarely need a business explanation.

Link styles

--link-style controls how cross-references render in generate output only (export has no such flag — its JSONL text is always md style, see RAG export shape below):

md (default) — standard markdown relative links: [users](../tables/users.md). Works in any renderer, GitHub included.
obsidian — Obsidian wikilinks: [[users]]. Use this when the output directory is opened as (or copied into) an Obsidian vault.

RAG export shape

dbmlgraph export writes one JSON object per line (JSONL), one chunk per table:

{"id": "orders", "domain": "commerce", "refs_out": ["users"], "refs_in": [], "text": "# orders\n..."}

text is the same rendered table markdown as tables/<name>.md (always in md link style, since embedding pipelines don't read wikilinks) — drop each line straight into a vector store as one chunk.

Context packs for agents

dbmlgraph query <table...> prints one self-contained context pack to stdout — built for pasting into an agent, so it never has to guess which files to open:

dbmlgraph query order_items orders -i schema.dbml --overlays overlays/

Full nodes for the queried tables, then a one-line hook per neighbor plus its keys: line (PK flag, FK target table(s), enum type — enough to join through the neighbor without opening its file), then merged rules — deduped across the whole pack. A queried table never shows up as its own neighbor, a neighbor shared by two queried tables prints once, and repeated FKs between the same pair collapse with a (2 refs collapsed) note. The footer names the tables just outside the pack and the command that fetches them.

flag	default	meaning
`--depth <n>`	`1`	neighbor hops, capped at 2. `0` drops the Neighbors section
`--budget <tokens>`	adaptive	by default the cap is sized to fit the queried nodes and every depth-1 neighbor's hook line + `keys:` line in full (min `4000`), so a hub table's direct partners are never degraded on a plain invocation; pass a number for a hard cap. Under pressure, neighbors degrade before they drop: depth-2+ entries lose their `keys:` line first (a direct depth-1 FK partner never does under the adaptive default), and only once nothing more can be trimmed does the tail get cut, ranked by distance then FK degree then name — queried nodes are never cut or degraded
`--columns key\|all`	`key`	`all` gives each neighbor a compact PK/FK/enum column table
`--format md\|json`	`md`	`json` mirrors the same sections as keys, plus `resolvedBudget` (the adaptive value actually used)
`--strict`	off	exact names only. Without it, a close name (case, or edit distance ≤2) is accepted when unambiguous

Truncation is never silent — a cut list always ends in a counted … and N more (raise --budget or --depth) label, and a run of key-column degradation ends in (N neighbors shown without columns — raise --budget). If even that isn't enough room for every direct relationship, the pack ships oversize rather than dropping one, with (budget exceeded to preserve direct relationships) noting why. An unresolvable name exits 1 after printing the three closest table names.

Does the pack actually work? We benchmarked it blind against a 70-table production schema: fresh agent sessions wrote SQL from either a pack (4–8k tokens) or the full raw DBML (~27k tokens). The pack matched or beat raw-dump accuracy at 3.5–6x less context, and on the hardest rule-dependent task the pack arm produced the only fully-correct answer. Method, results, and the two design changes the benchmark forced: docs/benchmark.md.

Find an identifier

find locates, query explains. Reach for find first when an agent doesn't yet know the exact table/column/enum name it needs — it's a wide, cheap lookup across every node kind (tables, columns, enums, enum values including overlay values: sets, domains), not a deep dump of one table's context.

dbmlgraph find cycle_id           # every column named cycle_id, across every table
dbmlgraph find KICKOFF            # an enum or enum-value hit — DBML enum or overlay values: set
dbmlgraph find planning_cycle     # a table hit (plus anything else matching the name)
dbmlgraph find "ratio_*"          # glob — quote it so the shell doesn't expand *

Matching runs in precedence order and stops at the first level that finds something: exact name (case-insensitive counts as exact) → glob (a term containing *) → fuzzy (edit distance ≤ 2), unless --strict is set. Multiple terms in one invocation are matched independently and their results concatenated.

flag	default	meaning
`--format md\|json`	`md`	`json` mirrors the same hit groups as keys
`--strict`	off	exact + glob only — skip the fuzzy fallback

Install AI-agent integration

install wires an agent up to find/query so it reaches for the schema graph instead of grepping markdown or DDL by hand.

dbmlgraph install claude [--global]     # writes .claude/skills/dbmlgraph/SKILL.md
dbmlgraph install agents                # writes/updates a marker-delimited AGENTS.md section
dbmlgraph install --list                # show install status for all targets
dbmlgraph uninstall claude|agents [--global]

install claude writes a Claude Code skill file — local by default (./.claude/skills/), or ~/.claude/skills/ with --global. install agents writes a  …  section into AGENTS.md at the project root, covering Codex, opencode, and any other agent that reads the AGENTS.md standard. Both installs bake in the resolved schema directory so the agent never has to guess -i/--overlays — one absolute cd in the generated instructions.

Schema directory resolution: --schema-dir <path> if given, otherwise walk up from the current directory looking for a .dbmlgraph.yml; no match in either case is an error.

install agents is idempotent — re-running it replaces only the content between the markers, so re-install after a schema move never duplicates the section or disturbs anything else in AGENTS.md. uninstall claude removes the skill directory; uninstall agents removes the marked section (and the whole file if nothing else is in it).

Roadmap

Ideas for future versions, roughly ordered by leverage. None are promises — they're the directions that fit the tool's shape (DBML in, overlays annotate, markdown out). Each notes where it would hook into the codebase. Pick one, open an issue, keep the diff small.

`coverage` — overlay completeness as a metric

lint already knows which tables lack a purpose and which columns lack meaning (W001/W002). A coverage command (or lint --report) would turn those counts into a percentage per domain and overall — "72% of columns documented" — so a large schema's annotation effort is trackable over time. Pure derivation from the existing lint pass in src/lint.ts.

`--watch` — regenerate on change

For the edit-schema / edit-overlay loop (and for schema-change automation hooks), a --watch flag on generate that re-runs on file change would remove the manual re-run step. fs.watch over the DBML file and overlays directory, calling the existing generate(); no new dependency needed.

`diff` — drift between two schema versions

dbmlgraph diff old.dbml new.dbml → the added/removed/changed tables, columns, and relationships. This is what a schema-migration workflow actually wants: "what rippled between these two versions." Two parseDbml calls and a structural comparison over the IR — a new src/diff.ts, no rendering changes.

Schema-wide relationship view

Per-domain ER diagrams exist (src/render/domain.ts); there's no single view of how domains connect to each other. A cross-domain edge summary (or Mermaid) in _index.md would give the whole-schema picture at a glance. Reads ir.refs + ir.domains, extends src/render/index.ts.

MCP server (phase 2)

query was built pure and side-effect-free on purpose (buildPack in src/query.ts takes an IR and options, returns a pack — no I/O, no process exit) so it could be reused outside the CLI. An MCP server exposing a single tool, dbmlgraph_query, would wrap that same function directly — CLI output and MCP output would be identical by construction, not two implementations to keep in sync.

License

MIT — see LICENSE.
