JetBot Vision Perception with YOLO

A ROS 2–based perception package designed for NVIDIA JetBot, providing real‑time object detection, depth‑aware perception, and flexible image transport pipelines. The system integrates YOLO models (including TensorRT‑optimized .engine builds) with ROS 2 nodes for image inference, overlay visualization, and compressed image streaming.

Here is a brief overview of the JetBot tools architecture

The diagram below illustrates how the three major JetBot tools interact within the overall system:

• JetBot Tools – the core utility layer providing shared infrastructure, helper scripts, and system‑level integrations.
• JetBot Voice-Activated Copilot Tools – the speech interface layer enabling ASR/TTS‑based voice control using NVIDIA Riva.
• JetBot Vision Perception Tools – the ROS2‑based perception stack offering YOLO detection, depth‑aware perception, and image transport pipelines.

Setup

• JetBot Vision Perception with YOLO Model Setup Guide



Jetbot ROS2 YOLO Detection Node

A ROS 2 node that performs real‑time object detection on incoming camera topics, publishes annotated overlays, and supports configurable model paths (e.g., TensorRT .engine files). Ideal for integrating with Nav2, depth cameras, or downstream perception modules.
It also outputs per‑object distance information, both embedded in the annotated overlay and included in the detection messages, allowing downstream nodes to fuse YOLO results with depth‑aware perception or obstacle‑avoidance logic.

Note:
The provided Docker image includes only the ROS2 source code—it does not come with ROS2 pre-installed or built.
On first-time launch inside the container, you must manually build the workspace with:

cd /ros2_ws && colcon build

You'll also see this reminder printed by run.sh if the /ros2_ws/install/setup.bash file is missing.

• Usage:

  # Navigate to the source directory
  cd ../ros2_ws
  # Build the package
  colcon build
  # Source the setup file
  . install/setup.bash
  # Launch YOLO detection node
  ros2 launch jetbot_vision_perception yolo_detection.launch.py
  ros2 run jetbot_vision_perception yolo_detection
  ros2 run jetbot_vision_perception yolo_detection --ros-args -p model_path:=/data/yolov11n.engine



Jetbot YOLO Image Detection Tool

A lightweight, standalone YOLO image‑inference tester located in the /app directory. Useful for validating exported YOLO models (engine or onnx) without launching ROS2.

• Usage:

  # Navigate to the /app directory cd /app
  # Run YOLO image detection
  python3 YOLO_detect.py [image_file] --model_path=<path> --format=<format>
  # Alternative ROS2-style parameter syntax
  python3 YOLO_detect.py [image_file] -p model_path:=<path> --format=<format>
  # Display help
  python3 YOLO_detect.py -? | -help

• Examples:

  python3 YOLO_detect.py ../out/bus.jpg
  python3 YOLO_detect.py ../out/bus.jpg --model_path=/data/yolov11n.engine --format=engine
  python3 YOLO_detect.py ../out/bus.jpg -p model_path:=/data/yolov11n.pt --format=onnx




Jetbot YOLO Webcam Detection Tool

A real‑time YOLO webcam detection utility located in the /app directory. This tool opens the specified webcam using OpenCV, performs YOLO inference on each frame, and displays the live annotated output. Useful for quickly validating YOLO models (engine or onnx) with a live camera feed outside ROS2.

• Usage:

  # Navigate to the /app directory
  cd /app

  # Run YOLO webcam detection
  python3 YOLO_detection_webcam.py [webcam_id] --model_path=<path>

  # Alternative ROS2-style parameter syntax
  python3 YOLO_detection_webcam.py [webcam_id] -p model_path:=<path>

  # Display help
  python3 YOLO_detection_webcam.py -? | -help

  • Examples:

  python3 YOLO_detection_webcam.py
  python3 YOLO_detection_webcam.py 0 --model_path=/data/yolov11n.engine
  python3 YOLO_detection_webcam.py 0 -p model_path:=/data/yolov11n.pt

  Note

  • To find available webcam IDs, run:


    v4l2-ctl --list-devices

  • To verify the webcam works properly:

   python3 webcam_test.py [webcam_id]

Image Transport Republish (Compression & Decompression)

To reduce bandwidth when transmitting image topics, ROS 2 provides the image_transport package. You can republish raw image topics as compressed streams, and then decompress them back to raw for downstream nodes.

• Compressing a Topic
  Use the raw → compressed pipeline to publish a compressed version of an existing image topic:

  ros2 run image_transport republish raw compressed \
    --ros-args \
    --remap in:=/yolo/overlay \
    --remap /out/compressed:=/yolo/in/compressed

• Decompressing a Topic
  Use the compressed → raw pipeline to restore the compressed stream back to a raw image:

    ros2 run image_transport republish compressed raw \
    --ros-args \
    --remap __ns:=/yolo \
    --remap in:=/in/compressed \
    --remap out:=overlay_decompressed

  References

• https://www.jetson-ai-lab.com/tutorial_ultralytics.html

  • YOLO 11

• https://github.com/mgonzs13/yolo_ros

• https://docs.ultralytics.com/reference/engine/results/

• https://github.com/Jen-Hung-Ho/ros2_jetbot_voice

• https://github.com/Jen-Hung-Ho/ros2_jetbot_tools
