diff --git a/.gitignore b/.gitignore index 4a502fb..fd6bdf4 100644 --- a/.gitignore +++ b/.gitignore @@ -19,4 +19,6 @@ bin/ .code-bee/ # Build output -worker +/worker + +.trae/ diff --git a/.trae/documents/runtime-scheduler-design.md b/.trae/documents/runtime-scheduler-design.md new file mode 100644 index 0000000..b5dbc6c --- /dev/null +++ b/.trae/documents/runtime-scheduler-design.md @@ -0,0 +1,255 @@ +# Runtime 调度器设计与实现计划 + +## Context + +### 问题 +code-bee 当前的调度策略硬编码在 `internal/pipeline/dispatch.go` 中： +- 角色固定（`BuiltinAgents()` 写死 6 个角色） +- 流程固定（`runCodingReviewLoop` 写死 coding→review→judge 的 3 轮循环） +- Loop 次数固定（`maxCodingReviewRounds=3`、`maxConsecutiveUnknownReview=2`） +- Prompt 模板固定（`prompts.go` 5 个 builder 函数，参数位置敏感） + +这导致非标准场景（无审查流、需要安全审查、不同角色分工等）无法适配。Issue #11 提出应让调度策略由场景驱动、外部加载。 + +### 已完成 +- `internal/schema/`：三层 YAML Schema（tool/stage/pipeline_step/loop/loop_judge/workflow）+ 配置加载器 + 语义校验 +- 工具别名支持（name + display_name + aliases） +- 三种编排原语（stage/parallel/loop）的 Schema 定义 + +### 本次目标 +实现 Runtime 调度器，基于 `*schema.Workflow` 配置驱动执行： +1. 新建 `internal/runtime/` 包，实现通用执行引擎 +2. **直接替换** `dispatch.go` 的硬编码逻辑（不共存） +3. **同步外部化** prompt 模板（从 `prompts.go` 抽到模板文件） +4. 复用现有文件契约（`.code-bee/runs/...`）和 `agent.Runner` + +## 设计决策 + +| 决策点 | 选择 | 理由 | +|--------|------|------| +| 与 dispatch.go 关系 | 直接替换 | 彻底统一，避免两套代码维护 | +| Prompt 模板 | 同步外部化 | 一步到位，避免临时方案 | +| 文件契约 | 复用现有 | agent 端零改动 | +| Tool 抽象 | 统一 Agent/Command/Function | 智能体本质是工具 | +| 状态收敛 | StepResult.Status 单字段 | 替代散落的 BlockedStatus/Passed/Unknown | + +## 包结构 + +``` +internal/runtime/ +├── doc.go # 包注释 +├── tool.go # Tool 接口 + StepResult + Invocation +├── tool_registry.go # ToolRegistry: 由 *schema.Workflow 构建 +├── agent_tool.go # AgentTool: 包装 agent.Runner +├── command_tool.go # CommandTool: exec.CommandContext +├── context.go # ExecutionContext + LoopState +├── expression.go # when / exit_when 表达式求值 +├── executor.go # Executor 接口 +├── stage_executor.go # StageExecutor +├── parallel_executor.go # ParallelExecutor (errgroup) +├── loop_executor.go # LoopExecutor +├── engine.go # Engine: 顶层入口 +├── prompt_builder.go # PromptBuilder 接口 + 模板加载 +└── *_test.go # 单元测试 + +internal/pipeline/ +├── contracts.go # 保留（Result 结构 + 状态枚举） +├── artifacts.go # 保留（ArtifactSet） +├── dispatch.go # 重构：Service.Dispatch 调用 runtime.Engine +├── prompts.go # 删除（模板移到 prompts/ 目录） +└── history.go # 保留（LoopHistory） + +prompts/ # 新增：外部化 prompt 模板 +├── coding.md +├── review.md +├── issue-handling.md +├── issue-post.md +└── loop-judge.md +``` + +## 核心接口 + +### Tool 接口 + +```go +type Tool interface { + Definition() *schema.Tool + Execute(ctx context.Context, inv Invocation) (*StepResult, error) +} + +type StepResult struct { + StageName string + Success bool + Blocked bool + Output string + Data map[string]any // 从 result file 加载的结构化结果 + Status string // = Data["status"]，统一状态字段 + Skipped bool // when=false 时 +} +``` + +### Executor 接口 + +```go +type Executor interface { + Execute(ctx context.Context, step schema.PipelineStep, ec *ExecutionContext) (*StepResult, error) +} +``` + +### Engine 顶层 + +```go +func New(wf *schema.Workflow, deps Dependencies) (*Engine, error) + +func (e *Engine) Run(ctx context.Context) (*pipeline.Result, error) +``` + +## 实现步骤 + +### 阶段 1：Prompt 模板外部化 + +**目标**：把 `prompts.go` 的 5 个 builder 抽到 `prompts/` 目录的模板文件 + +**改动**： +1. 创建 `prompts/` 目录，写 5 个 `.md` 模板文件（用 Go `text/template` 语法） +2. `internal/runtime/prompt_builder.go`：实现 PromptBuilder，从文件加载模板渲染 +3. 删除 `internal/pipeline/prompts.go` +4. 调整 `dispatch.go` 中对 `buildXxxPrompt` 的调用（临时保留，阶段 5 会删） + +**关键**：模板文件用 `{{.WorkerID}}`、`{{.IssueURL}}`、`{{.Round}}` 等命名参数，替代位置敏感的 `%s/%d` + +### 阶段 2：Runtime 核心数据结构（P1） + +**文件**：`tool.go`、`tool_registry.go`、`context.go` + +**内容**： +- `Tool` 接口、`StepResult`、`Invocation`、`PlatformContext` +- `ToolRegistry`：由 `*schema.Workflow` 构建，支持 name + alias 查找（复用 `Workflow.FindTool`） +- `ExecutionContext`：`stages map[string]*StepResult` + `loopStack []*LoopState` +- `LoopState`：`Round`、`MaxIterations`、`ConsecutiveUnknown`、`LastFeedback` +- `Lookup(stageName, fieldPath)` 支持 dot path 嵌套取值 +- `Snapshot()` / `Merge()` 用于 parallel 写隔离 + +### 阶段 3：表达式求值（P2） + +**文件**：`expression.go` + +**内容**： +- 结构化 `ExitCondition` 求值：6 个 operator（equals/not_equals/in/contains/exists/regex） +- 字符串表达式最小解析器：支持 `round >= 2`、`review.status == "PASS"` 等 +- 复用 `ExecutionContext.Lookup` 取值 + +### 阶段 4：三种 Tool 实现（P3） + +**文件**：`agent_tool.go`、`command_tool.go`、`prompt_builder.go` + +**内容**： +- `AgentTool`：包装 `agent.Runner`，调 `runner.Run(ctx, kind, prompt)` → 加载 result file → `StepResult` +- `CommandTool`：`exec.CommandContext("sh", "-c", run)` → 解析 stdout JSON → `StepResult` +- `PromptBuilder`：从 `prompts/` 加载模板，用 `Invocation` 渲染 +- `mapTemplateToKind`：`coding→TaskKindCoding` 等映射表 + +### 阶段 5：StageExecutor（P4） + +**文件**：`stage_executor.go` + +**流程**： +1. `registry.Resolve(stage.Tool)` → Tool +2. 求 `stage.When`，false 则返回 `Skipped` +3. `ec.Lookup(stage.InputFrom, "")` 拿上游数据 +4. `tool.Execute(ctx, inv)` → `StepResult` +5. `ec.SetResult(stage.Name, result)` +6. 处理 `on_blocked`：stop/skip/continue + +### 阶段 6：ParallelExecutor（P5） + +**文件**：`parallel_executor.go` + +**流程**： +1. `errgroup.WithContext(ctx)` 并发执行分支 +2. 每分支用 `ec.CloneForBranch()` 写隔离 +3. Join 策略： + - `all`：全成功才成功 + - `any`：任一成功即成功 + - `first_success`：首个成功后 `context.WithCancel` 取消其他 +4. 成功分支结果 `Merge` 回主 ec + +### 阶段 7：LoopExecutor（P6） + +**文件**：`loop_executor.go` + +**流程**： +``` +for round := 1; round <= maxIterations; round++ { + 执行 body 中每个 step + 每步后检查 exit_when（命中则退出） + 维护 ConsecutiveUnknown（超限则 ManualRequired 退出） + 若配了 judge 且 round >= startRound：执行 judge + STOP_MANUAL → ManualRequired 退出 + STOP_BLOCKED → Blocked 退出 + SHRINK_TASK → 注入反馈继续 + CONTINUE → 继续 +} +跑完 maxIterations → ManualRequired +``` + +### 阶段 8：Engine + 重构 dispatch.go（P7） + +**文件**：`engine.go`、`dispatch.go`（重构） + +**改动**： +1. `runtime.Engine.Run(ctx)`：遍历 `wf.Pipeline`，`pickExecutor` 分发执行 +2. 重构 `pipeline.Service`： + - `Dispatch(ctx, cfg)` 改为调用 `runtime.Engine` + - 删除 `runCodingReviewLoop` / `runIssueHandling` / `runCodingRound` 等硬编码函数 + - 保留 `contracts.go`（Result 结构）、`artifacts.go`（ArtifactSet）、`history.go`（LoopHistory） +3. `cmd/worker/main.go`：加载 workflow.yaml → 构造 Engine → 调用 Service +4. 调整现有测试：`dispatch_test.go`、`loop_judge_test.go`、`coverage_test.go` 改为基于 workflow 配置测试 + +## 测试策略 + +### 单元测试（runtime 包） +- `tool_test.go`：AgentTool/CommandTool，用 scriptedRunner + fakeExec mock +- `context_test.go`：Lookup 嵌套字段、Snapshot/Merge 隔离、LoopStack +- `expression_test.go`：6 operator + 字符串表达式全覆盖 +- `stage_executor_test.go`：when 跳过、on_blocked 三策略、input_from 注入 +- `parallel_executor_test.go`：all/any/first_success + cancel 行为 +- `loop_executor_test.go`：exit_when 命中、judge 四种决策、max_consecutive_unknown、max_iterations、嵌套 loop + +### 集成测试 +- 用 `schema/testdata/valid/loop_with_judge.yaml` 端到端跑通 +- 用 `parallel_pipeline.yaml`、`nested_loop.yaml` 验证编排原语 + +### 重构后的 pipeline 测试 +- `dispatch_test.go` 改为：加载 workflow.yaml → Engine.Run → 断言 Result +- 保持原有测试覆盖意图（blocked/manual/completion 等场景） + +## 验证方法 + +1. **单元测试**：`go test ./internal/runtime/... -v -cover`，覆盖率 >= 80% +2. **集成测试**：`go test ./internal/pipeline/... -v`，原有场景全部通过 +3. **全项目测试**：`go test ./...` 全绿 +4. **构建验证**：`go build ./...` 无错误 +5. **Lint**：`go vet ./...` 无警告 + +## 关键文件 + +| 文件 | 操作 | 说明 | +|------|------|------| +| `internal/runtime/*.go` | 新增 | 完整调度引擎 | +| `internal/pipeline/dispatch.go` | 重构 | 删除硬编码 loop，改调 runtime.Engine | +| `internal/pipeline/prompts.go` | 删除 | 模板移到 `prompts/` 目录 | +| `internal/pipeline/contracts.go` | 保留 | Result 结构 + 状态枚举 | +| `internal/pipeline/artifacts.go` | 保留 | ArtifactSet 复用 | +| `prompts/*.md` | 新增 | 5 个外部化 prompt 模板 | +| `cmd/worker/main.go` | 修改 | 加载 workflow.yaml | +| `internal/pipeline/dispatch_test.go` | 调整 | 改为基于 workflow 配置测试 | + +## 风险与缓解 + +| 风险 | 缓解 | +|------|------| +| 重构破坏现有测试 | 分阶段提交，每阶段测试通过再继续 | +| Prompt 模板外部化改变行为 | 保持模板内容与原 prompts.go 等价，逐字对照 | +| Loop 行为不一致 | 保留 LoopHistory 持久化逻辑，状态迁移完整 | +| 文件契约破坏 | 复用 ArtifactSet，agent 端零改动 | diff --git a/README.md b/README.md index c0010d6..9b82b1a 100644 --- a/README.md +++ b/README.md @@ -17,7 +17,7 @@ - **Issue 即任务面板** —— 不需要额外工具，GitHub Issue 就是你的任务系统 - **@ mention 即调度** —— `@agent-frontend` 重构组件、`@agent-backend` 修 bug，像 @ 同事一样自然 - **零侵入** —— code-bee 本身不触碰你的代码，所有操作由智能体独立完成 -- **极简内核** —— 不到 100 行核心逻辑，易于理解、审计和贡献 +- **场景驱动调度** —— 角色体系和管线流程由 YAML workflow 配置驱动，不再硬编码；内置默认开箱即用，`--workflow` 支持完全自定义 --- @@ -27,12 +27,216 @@ |------|------|------| | 🧠 编码智能体 | [Reasonix](https://github.com/tryreasonix/reasonix) × [DeepSeek](https://www.deepseek.com/) | 接收任务指令，自主完成读 Issue → 编码 → 提 PR 全流程 | | 🔧 Git 操作 | [GitHub CLI (`gh`)](https://cli.github.com/) | 智能体通过 `gh` 完成 fork、clone、commit、push、create PR | -| 🏗️ 调度器 | **code-bee** (Go 1.23+) | 解析 Issue 中的 @agent，生成任务指令，交给智能体执行 | +| 🏗️ 调度器 | **code-bee** (Go 1.23+) | 解析 Issue 中的 @agent，按 workflow 配置编排 stage/parallel/loop，驱动智能体执行 | | ✅ 代码校验 | [golangci-lint](https://golangci-lint.run/) + [conform](https://github.com/talos-systems/conform) | 静态分析 + 目录结构校验 | ### 架构一览 -![四阶段架构](https://raw.githubusercontent.com/JiGuangWorker/code-bee/main/docs/images/readme/02-architecture.png) +code-bee 采用 **四层分层架构**：CLI 入口 → pipeline 薄封装 → runtime 核心引擎 → schema 配置定义。调度策略完全由 `workflow.yaml` 驱动，runtime.Engine 遍历 Pipeline 并按终止语义决定提前返回或继续。 + +#### 分层组件架构 + +```mermaid +flowchart TB + subgraph CLI["cmd/worker · CLI 入口"] + main["main() → runCLI()"] + build["buildService()
parseExtraFlags + loadWorkflow"] + report["reportDispatchResult()
Result → 退出码"] + end + + subgraph Schema["internal/schema · 配置定义"] + loader["Loader
YAML + 三层 JSON Schema 校验"] + types["Workflow / Tool / Stage
Loop / Condition / LoopJudge"] + end + + subgraph Pipe["internal/pipeline · 薄封装层"] + svc["Service
持有 *Engine + *Workflow"] + arts["ArtifactSet
文件契约目录"] + adapt["ArtifactResolverAdapter
ArtifactSet ⇄ ArtifactResolver"] + contracts["contracts.go
typed result loaders"] + end + + subgraph RT["internal/runtime · 核心引擎"] + eng["Engine
遍历 Pipeline + 终止语义"] + reg["ToolRegistry
name/alias → Tool"] + pb["PromptBuilder
embed 内置 + overlay 外部"] + ec["ExecutionContext
stages map + loopStack"] + se["StageExecutor"] + pe["ParallelExecutor
fork-join 写隔离"] + le["LoopExecutor
max_iter / exit_when / judge"] + at["AgentTool
render + runner.Run"] + ct["CommandTool
exec.CommandContext"] + ft["FunctionTool (桩)"] + arIface["«interface»
ArtifactResolver"] + runnerIface["«interface»
Runner"] + end + + subgraph Ext["外部依赖"] + agentRunner["agent.Runner
Reasonix × DeepSeek"] + platformClient["platform.Client
GitHub"] + end + + main --> build + build -->|"加载 workflow"| loader + loader --> types + build --> svc + main -->|"Dispatch(ctx, cfg)"| svc + platformClient --> svc + svc --> eng + svc --> arts + arts --> adapt + eng --> ec + eng --> se + eng --> pe + eng --> le + se --> reg + reg --> at + reg --> ct + reg --> ft + at --> pb + at --> runnerIface + runnerIface -.->|"实现"| agentRunner + at -->|"LoadResult"| arIface + arIface -.->|"实现"| adapt + adapt --> contracts + svc -->|"EngineResult → Result"| report +``` + +**分层职责**： + +| 层 | 包 | 职责 | +|----|----|------| +| CLI | `cmd/worker` | flag 解析、workflow 加载、构造 Service、退出码映射 | +| pipeline | `internal/pipeline` | 薄封装层：持有 Engine、管理文件契约目录、typed 结果校验 | +| runtime | `internal/runtime` | 核心引擎：编排原语执行器、工具注册表、prompt 渲染、上下文管理 | +| schema | `internal/schema` | 配置定义：YAML 加载 + 三层 JSON Schema 语义校验 | + +**关键解耦**：runtime 包通过 `ArtifactResolver` 和 `Runner` 两个接口与外部解耦——pipeline 层用 `ArtifactResolverAdapter` 桥接文件契约，CLI 注入真实的 `agent.Runner` 实现。runtime 不依赖 pipeline（避免循环依赖）。 + +#### Dispatch 调用链路 + +下图展示单次 `Dispatch` 从 CLI 到智能体执行的完整调用链，含结果文件读写时序： + +```mermaid +sequenceDiagram + participant CLI as runCLI + participant Svc as Service.Dispatch + participant Eng as Engine.Run + participant SE as StageExecutor + participant Tool as AgentTool + participant PB as PromptBuilder + participant Runner as agent.Runner + participant AR as ArtifactResolver + participant FS as 文件系统 + + CLI->>Svc: Dispatch(ctx, cfg) + Svc->>Svc: 创建 ArtifactSet + PlatformContext + Svc->>Svc: 包装 ArtifactResolverAdapter + Svc->>Eng: Run(deps{Artifacts, Platform, Config}) + Eng->>Eng: NewExecutionContext + loop 遍历 workflow.Pipeline + Eng->>SE: Execute(step, ec) + SE->>SE: 求值 when 条件 + SE->>SE: registry.Resolve(tool) + SE->>AR: ResolveResultFile(stageName) + AR-->>SE: resultFilePath + SE->>FS: ResetResultFile(删除旧文件) + SE->>SE: ec.Lookup(input_from) + SE->>Tool: Execute(Invocation) + Tool->>PB: Build(promptTemplate, data) + PB-->>Tool: rendered prompt + Tool->>Runner: Run(ctx, kind, prompt) + Runner-->>Tool: RunResult{Output} + Tool->>AR: LoadResult(stageName, path) + AR->>FS: 读取结果文件 + AR-->>Tool: map[string]any + Tool->>Tool: extractStatus → StepResult + Tool-->>SE: StepResult + SE->>SE: ec.SetResult + SE-->>Eng: StepResult + alt Blocked / ManualRequired / Completed + Eng-->>Svc: 提前返回 EngineResult + end + end + Eng-->>Svc: EngineResult + Svc-->>CLI: pipeline.Result +``` + +**关键时序点**： +1. **StageExecutor 先 reset 结果文件**——防止读到上一轮残留数据 +2. **AgentTool 渲染 prompt 后才调 runner**——prompt 数据由 `buildPromptData` 从 ExecutionContext 派生 +3. **结果文件是 stage 间通信媒介**——`ec.SetResult` 存内存快照供 `when`/`exit_when` 求值，`LoadResult` 读磁盘文件做 typed 校验 +4. **终止语义即时生效**——任一 stage 返回 `Blocked`/`ManualRequired`/`Completed`，Engine 立即跳出 Pipeline 循环返回 + +#### 配置加载与数据流 + +下图展示 workflow + prompt 模板的加载链，以及结果文件在 stage 间的流转： + +```mermaid +flowchart LR + subgraph 配置加载["配置加载（启动时一次性）"] + direction TB + embedWf["default_workflow.yaml
(go:embed)"] + extWf["--workflow xxx.yaml"] + loader["schema.Loader
YAML + Schema 校验"] + wf["*schema.Workflow"] + + embedP["prompts/*.md
(go:embed, 5 个内置)"] + extP["--prompts-dir ./dir/"] + pb["PromptBuilder
overlay 同名覆盖"] + templates["templates map"] + + embedWf --> loader + extWf --> loader + loader --> wf + embedP --> pb + extP --> pb + pb --> templates + end + + subgraph 运行时["运行时数据流（Dispatch 时）"] + direction TB + cfg["Config
Repo/Issue"] + arts["ArtifactSet
.code-bee/runs/repo/issue-N/"] + ec["ExecutionContext
stages map"] + + s1["stage: issue-handling
